Fenix AT Series

-Maximum height: 5m
-Maximum load: 200kg
-Height folded: 1,59m
-Weight: 93kg
-Winch: AL-KO 900 Compact 900kg
-Workspace: 1,45 x 1,49m
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Closed base area: 0,38 x 0,48m
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-04-2/

-Maximum height: 5m
-Maximum load: 200kg
-Height folded: 1,59m
-Weight: 93kg
-Winch: AL-KO 900 Compact 900kg
-Workspace: 1,45 x 1,49m
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Closed base area: 0,38 x 0,48m
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-04b-2/

-Maximum height: 5,40m
-Maximum load: 250kg
-Height folded: 1,76m
-Weight: 96Kg
-Winch: AL-KO 900 Compact 900kg
-Workspace: 1,66 x 1,72m
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Closed base area: 0,48 x 0,48m
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-05-2/

-Maximum height: 5,40m
-Maximum load: 250kg
-Height folded: 1,76m
-Weight: 96Kg
-Winch: AL-KO 900 Compact 900kg
-Workspace: 1,66 x 1,72m
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Closed base area: 0,48 x 0,48m
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-05b-2/

-Maximum height: 6,50m
-Maximum load: 250kg
-Height folded: 1,76m
-Weight: 111kg
-Winch: AL-KO Type 900 Compact 900kg
-Workspace: 1,66 x 1,72cm
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Closed base area: 0,48 x 0,48m
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-06-2/

-Maximum height: 6,50m
-Maximum load: 250kg
-Height folded: 1,76m
-Weight: 111kg
-Winch: AL-KO Type 900 Compact 900kg
-Workspace: 1,66 x 1,72cm
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-06-compact-2/

-Maximum height: 6,50m
-Maximum load: 250kg
-Height folded: 1,76m
-Weight: 111kg
-Winch: AL-KO Type 900 Compact 900kg
-Workspace: 1,66 x 1,72cm
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Closed base area: 0,48 x 0,48m
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-06b-2/

-Maximum height: 6,50m
-Maximum load: 250kg
-Height folded: 1,76m
-Weight: 111kg
-Winch: AL-KO Type 900 Compact 900kg
-Workspace: 1,66 x 1,72cm
-Minimum charge: 25kg
-Material: Aluminium AL Si 6082 / T6
-Cable: Galvanized steel under EN 12385-4.
-Maximum cable load: 2.870kg
-Cable twisting resistance : 1.770N/mm²
-Cable diameter: 6mm
-Cable composition: 7×19+0
-Security system: Inner pendulum and external trigger in sections.
-Bubble level: to vertically adjust the tower.
-Leg attachment: Safety pins
For more info please visit : https://fenixstage.com/en/tienda/at-06b-compact-2/
